30 Programming Design Patterns
Nurul Huda (Apon) / July 13, 2024
18 min read • ––– views
1. Singleton Pattern
Ensures a class has only one instance and provides a global point of access to it.
When to use: When exactly one instance of a class is needed to control the action.
Why to use: To prevent multiple instances of a class and provide a single point of access.
class Singleton {
private static instance: Singleton;
private constructor() {}
static getInstance(): Singleton {
if (!Singleton.instance) {
Singleton.instance = new Singleton();
}
return Singleton.instance;
}
}
const instance1 = Singleton.getInstance();
const instance2 = Singleton.getInstance();
console.log(instance1 === instance2); // true
2. Factory Pattern
Creates objects without specifying the exact class of object that will be created.
When to use: When the exact type of the object is determined at runtime.
Why to use: To encapsulate object creation.
interface Product {
operation(): string;
}
class ConcreteProduct1 implements Product {
operation(): string {
return 'ConcreteProduct1';
}
}
class ConcreteProduct2 implements Product {
operation(): string {
return 'ConcreteProduct2';
}
}
class Creator {
static factoryMethod(type: string): Product {
if (type === '1') {
return new ConcreteProduct1();
} else {
return new ConcreteProduct2();
}
}
}
const product1 = Creator.factoryMethod('1');
console.log(product1.operation()); // ConcreteProduct1
3. Abstract Factory Pattern
Provides an interface for creating families of related or dependent objects without specifying their concrete classes.
When to use: When families of related objects need to be created.
Why to use: To ensure consistency among products.
interface AbstractFactory {
createProductA(): AbstractProductA;
createProductB(): AbstractProductB;
}
class ConcreteFactory1 implements AbstractFactory {
createProductA(): AbstractProductA {
return new ProductA1();
}
createProductB(): AbstractProductB {
return new ProductB1();
}
}
interface AbstractProductA {
usefulFunctionA(): string;
}
interface AbstractProductB {
usefulFunctionB(): string;
}
class ProductA1 implements AbstractProductA {
usefulFunctionA(): string {
return 'The result of ProductA1';
}
}
class ProductB1 implements AbstractProductB {
usefulFunctionB(): string {
return 'The result of ProductB1';
}
}
const factory1 = new ConcreteFactory1();
const productA1 = factory1.createProductA();
const productB1 = factory1.createProductB();
console.log(productA1.usefulFunctionA()); // The result of ProductA1
console.log(productB1.usefulFunctionB()); // The result of ProductB1
4. Builder Pattern
Separates the construction of a complex object from its representation, allowing the same construction process to create various representations.
When to use: When an object needs to be created with various configurations.
Why to use: To construct a complex object step by step.
class Product {
public parts: string[] = [];
public listParts(): void {
console.log(`Product parts: ${this.parts.join(', ')}`);
}
}
class Builder {
private product: Product;
constructor() {
this.product = new Product();
}
public reset(): void {
this.product = new Product();
}
public addPartA(): void {
this.product.parts.push('PartA');
}
public addPartB(): void {
this.product.parts.push('PartB');
}
public getProduct(): Product {
return this.product;
}
}
const builder = new Builder();
builder.addPartA();
builder.addPartB();
const product = builder.getProduct();
product.listParts(); // Product parts: PartA, PartB
5. Prototype Pattern
Creates new objects by copying an existing object, known as the prototype.
When to use: When the cost of creating a new object is expensive.
Why to use: To reduce the cost of creating objects.
class Prototype {
public primitive: any;
public component: object;
public circularReference: ComponentWithBackReference;
public clone(): this {
const clone = Object.create(this);
clone.component = Object.create(this.component);
clone.circularReference = {
...this.circularReference,
prototype: { ...this }
};
return clone;
}
}
class ComponentWithBackReference {
public prototype;
constructor(prototype: Prototype) {
this.prototype = prototype;
}
}
const prototype = new Prototype();
prototype.primitive = 245;
prototype.component = new Date();
prototype.circularReference = new ComponentWithBackReference(prototype);
const clone = prototype.clone();
console.log(clone.primitive); // 245
console.log(clone.component); // Date object
console.log(clone.circularReference.prototype === prototype); // false
6. Adapter Pattern
Allows incompatible interfaces to work together.
When to use: When you want to use an existing class, but its interface is not compatible with the rest of your code.
Why to use: To enable collaboration between classes with incompatible interfaces.
class Target {
request(): string {
return 'Target: The default target\'s behavior.';
}
}
class Adaptee {
specificRequest(): string {
return '.eetpadA eht fo roivaheb laicepS';
}
}
class Adapter extends Target {
private adaptee: Adaptee;
constructor(adaptee: Adaptee) {
super();
this.adaptee = adaptee;
}
request(): string {
return `Adapter: (TRANSLATED) ${this.adaptee.specificRequest().split('').reverse().join('')}`;
}
}
const adaptee = new Adaptee();
const adapter = new Adapter(adaptee);
console.log(adapter.request()); // Adapter: (TRANSLATED) Special behavior of the Adaptee.
7. Bridge Pattern
Decouples an abstraction from its implementation so that the two can vary independently.
When to use: When you want to separate a monolithic class into several class hierarchies.
Why to use: To avoid a permanent binding between an abstraction and its implementation.
interface Implementation {
operationImplementation(): string;
}
class ConcreteImplementationA implements Implementation {
operationImplementation(): string {
return 'ConcreteImplementationA: Here\'s the result on the platform A.';
}
}
class ConcreteImplementationB implements Implementation {
operationImplementation(): string {
return 'ConcreteImplementationB: Here\'s the result on the platform B.';
}
}
class Abstraction {
protected implementation: Implementation;
constructor(implementation: Implementation) {
this.implementation = implementation;
}
operation(): string {
return `Abstraction: Base operation with:\n${this.implementation.operationImplementation()}`;
}
}
const implementationA = new ConcreteImplementationA();
let abstraction = new Abstraction(implementationA);
console.log(abstraction.operation()); // Abstraction: Base operation with: ConcreteImplementationA: Here's the result on the platform A.
const implementationB = new ConcreteImplementationB();
abstraction = new Abstraction(implementationB);
console.log(abstraction.operation()); // Abstraction: Base operation with: ConcreteImplementationB: Here's the result on the platform B.
8. Composite Pattern
Composes objects into tree structures to represent part-whole hierarchies.
When to use: When you need to treat individual objects and compositions of objects uniformly.
Why to use: To simplify client code that deals with complex tree structures.
interface Component {
operation(): string;
}
class Leaf implements Component {
operation(): string {
return 'Leaf';
}
}
class Composite implements Component {
private children: Component[] = [];
add(component: Component): void {
this.children.push(component);
}
remove(component: Component): void {
const index = this.children.indexOf(component);
this.children.splice(index, 1);
}
operation(): string {
const results = [];
for (const child of this.children) {
results.push(child.operation());
}
return `Branch(${results.join('+')})`;
}
}
const leaf = new Leaf();
const tree = new Composite();
const branch1 = new Composite();
const branch2 = new Composite();
branch1.add(leaf);
branch2.add(leaf);
tree.add(branch1);
tree.add(branch2);
console.log(tree.operation()); // Branch(Branch(Leaf)+Branch(Leaf))
9. Decorator Pattern
Adds additional responsibilities to an object dynamically.
When to use: When you need to add responsibilities to objects dynamically.
Why to use: To avoid subclassing for functionalities.
interface Component {
operation(): string;
}
class ConcreteComponent implements Component {
operation(): string {
return 'ConcreteComponent';
}
}
class Decorator implements Component {
protected component: Component;
constructor(component: Component) {
this.component = component;
}
operation(): string {
return this.component.operation();
}
}
class ConcreteDecoratorA extends Decorator {
operation(): string {
return `ConcreteDecoratorA(${super.operation()})`;
}
}
class ConcreteDecoratorB extends Decorator {
operation(): string {
return `ConcreteDecoratorB(${super.operation()})`;
}
}
const simple = new ConcreteComponent();
console.log(simple.operation()); // ConcreteComponent
const decorator1 = new ConcreteDecoratorA(simple);
const decorator2 = new ConcreteDecoratorB(decorator1);
console.log(decorator2.operation()); // ConcreteDecoratorB(ConcreteDecoratorA(ConcreteComponent))
10. Facade Pattern
Provides a simplified interface to a complex subsystem.
When to use: When you need to provide a simple interface to a complex subsystem.
Why to use: To hide the complexities of the system.
class Subsystem1 {
operation1(): string {
return 'Subsystem1: Ready!';
}
operationN(): string {
return 'Subsystem1: Go!';
}
}
class Subsystem2 {
operation1(): string {
return 'Subsystem2: Get ready!';
}
operationZ(): string {
return 'Subsystem2: Fire!';
}
}
class Facade {
protected subsystem1: Subsystem1;
protected subsystem2: Subsystem2;
constructor(subsystem1: Subsystem1, subsystem2: Subsystem2) {
this.subsystem1 = subsystem1;
this.subsystem2 = subsystem2;
}
operation(): string {
let result = 'Facade initializes subsystems:\n';
result += this.subsystem1.operation1() + '\n';
result += this.subsystem2.operation1() + '\n';
result += 'Facade orders subsystems to perform the action:\n';
result += this.subsystem1.operationN() + '\n';
result += this.subsystem2.operationZ();
return result;
}
}
const subsystem1 = new Subsystem1();
const subsystem2 = new Subsystem2();
const facade = new Facade(subsystem1, subsystem2);
console.log(facade.operation());
11. Flyweight Pattern
Uses sharing to support large numbers of fine-grained objects efficiently.
When to use: When a large number of similar objects are needed.
Why to use: To reduce memory consumption.
class Flyweight {
private sharedState: any;
constructor(sharedState: any) {
this.sharedState = sharedState;
}
operation(uniqueState: any): void {
const s = JSON.stringify(this.sharedState);
const u = JSON.stringify(uniqueState);
console.log(`Flyweight: Displaying shared (${s}) and unique (${u}) state.`);
}
}
class FlyweightFactory {
private flyweights: { [key: string]: Flyweight } = {};
constructor(initialFlyweights: string[][]) {
for (const state of initialFlyweights) {
this.flyweights[this.getKey(state)] = new Flyweight(state);
}
}
private getKey(state: string[]): string {
return state.join('_');
}
getFlyweight(sharedState: string[]): Flyweight {
const key = this.getKey(sharedState);
if (!(key in this.flyweights)) {
console.log('FlyweightFactory: Can\'t find a flyweight, creating new one.');
this.flyweights[key] = new Flyweight(sharedState);
} else {
console.log('FlyweightFactory: Reusing existing flyweight.');
}
return this.flyweights[key];
}
}
const factory = new FlyweightFactory([
['Chevrolet', 'Camaro2018', 'pink'],
['Mercedes Benz', 'C300', 'black'],
['Mercedes Benz', 'C500', 'red'],
]);
const flyweight1 = factory.getFlyweight(['Chevrolet', 'Camaro2018', 'pink']);
flyweight1.operation(['John Doe', 'CL234IR']);
const flyweight2 = factory.getFlyweight(['Mercedes Benz', 'C300', 'black']);
flyweight2.operation(['Jane Doe', 'CL234IR']);
12. Proxy Pattern
Provides a surrogate or placeholder for another object to control access to it.
When to use: When you need a more versatile or sophisticated reference to an object.
Why to use: To control access and add additional functionality.
interface Subject {
request(): void;
}
class RealSubject implements Subject {
request(): void {
console.log('RealSubject: Handling request.');
}
}
class Proxy implements Subject {
private realSubject: RealSubject;
constructor(realSubject: RealSubject) {
this.realSubject = realSubject;
}
request(): void {
if (this.checkAccess()) {
this.realSubject.request();
this.logAccess();
}
}
private checkAccess(): boolean {
console.log('Proxy: Checking access prior to firing a real request.');
return true;
}
private logAccess(): void {
console.log('Proxy: Logging the time of request.');
}
}
const realSubject = new RealSubject();
const proxy = new Proxy(realSubject);
proxy.request(); // Proxy: Checking access prior to firing a real request. RealSubject: Handling request. Proxy: Logging the time of request.
13. Chain of Responsibility Pattern
Passes a request along a chain of handlers.
When to use: When more than one object can handle a request.
Why to use: To decouple sender and receiver.
interface Handler {
setNext(handler: Handler): Handler;
handle(request: string): string;
}
abstract class AbstractHandler implements Handler {
private nextHandler: Handler;
public setNext(handler: Handler): Handler {
this.nextHandler = handler;
return handler;
}
public handle(request: string): string {
if (this.nextHandler) {
return this.nextHandler.handle(request);
}
return null;
}
}
class MonkeyHandler extends AbstractHandler {
public handle(request: string): string {
if (request === 'Banana') {
return `Monkey: I'll eat the ${request}.`;
}
return super.handle(request);
}
}
class SquirrelHandler extends AbstractHandler {
public handle(request: string): string {
if (request === 'Nut') {
return `Squirrel: I'll eat the ${request}.`;
}
return super.handle(request);
}
}
const monkey = new MonkeyHandler();
const squirrel = new SquirrelHandler();
monkey.setNext(squirrel);
console.log(monkey.handle('Banana')); // Monkey: I'll eat the Banana.
console.log(monkey.handle('Nut')); // Squirrel: I'll eat the Nut.
14. Command Pattern
Turns a request into a stand-alone object that contains all information about the request.
When to use: When you want to parameterize objects with operations.
Why to use: To encapsulate requests as objects.
interface Command {
execute(): void;
}
class SimpleCommand implements Command {
private payload: string;
constructor(payload: string) {
this.payload = payload;
}
public execute(): void {
console.log(`SimpleCommand: See, I can do simple things like printing (${this.payload})`);
}
}
class ComplexCommand implements Command {
private receiver: Receiver;
private a: string;
private b: string;
constructor(receiver: Receiver, a: string, b: string) {
this.receiver = receiver;
this.a = a;
this.b = b;
}
public execute(): void {
console.log('ComplexCommand: Complex stuff should be done by a receiver object.');
this.receiver.doSomething(this.a);
this.receiver.doSomethingElse(this.b);
}
}
class Receiver {
public doSomething(a: string): void {
console.log(`Receiver: Working on (${a}).`);
}
public doSomethingElse(b: string): void {
console.log(`Receiver: Also working on (${b}).`);
}
}
class Invoker {
private onStart: Command;
private onFinish: Command;
public setOnStart(command: Command): void {
this.onStart = command;
}
public setOnFinish(command: Command): void {
this.onFinish = command;
}
public doSomethingImportant(): void {
if (this.onStart) {
this.onStart.execute();
}
if (this.onFinish) {
this.onFinish.execute();
}
}
}
const invoker = new Invoker();
invoker.setOnStart(new SimpleCommand('Say Hi!'));
const receiver = new Receiver();
invoker.setOnFinish(new ComplexCommand(receiver, 'Send email', 'Save report'));
invoker.doSomethingImportant();
15. Iterator Pattern
Provides a way to access elements of a collection sequentially without exposing its underlying representation.
When to use: When you need to traverse a collection without exposing its implementation.
Why to use: To provide a standard way to iterate over a collection.
interface Iterator<T> {
next(): T;
hasNext(): boolean;
}
interface Aggregator {
getIterator(): Iterator<string>;
}
class ConcreteIterator implements Iterator<string> {
private collection: ConcreteCollection;
private position: number = 0;
constructor(collection: ConcreteCollection) {
this.collection = collection;
}
public next(): string {
const item = this.collection.items[this.position];
this.position += 1;
return item;
}
public hasNext(): boolean {
return this.position < this.collection.items.length;
}
}
class ConcreteCollection implements Aggregator {
public items: string[] = [];
public getIterator(): Iterator<string> {
return new ConcreteIterator(this);
}
}
const collection = new ConcreteCollection();
collection.items.push('Item 1');
collection.items.push('Item 2');
collection.items.push('Item 3');
const iterator = collection.get
Iterator();
while (iterator.hasNext()) {
console.log(iterator.next());
}
16. Mediator Pattern
Defines an object that encapsulates how a set of objects interact.
When to use: When you need to reduce the complexity of communication between objects.
Why to use: To promote loose coupling by keeping objects from referring to each other explicitly.
interface Mediator {
notify(sender: object, event: string): void;
}
class ConcreteMediator implements Mediator {
private component1: Component1;
private component2: Component2;
constructor(c1: Component1, c2: Component2) {
this.component1 = c1;
this.component1.setMediator(this);
this.component2 = c2;
this.component2.setMediator(this);
}
public notify(sender: object, event: string): void {
if (event === 'A') {
console.log('Mediator reacts on A and triggers following operations:');
this.component2.doC();
}
if (event === 'D') {
console.log('Mediator reacts on D and triggers following operations:');
this.component1.doB();
this.component2.doC();
}
}
}
class BaseComponent {
protected mediator: Mediator;
public setMediator(mediator: Mediator): void {
this.mediator = mediator;
}
}
class Component1 extends BaseComponent {
public doA(): void {
console.log('Component 1 does A.');
this.mediator.notify(this, 'A');
}
public doB(): void {
console.log('Component 1 does B.');
this.mediator.notify(this, 'B');
}
}
class Component2 extends BaseComponent {
public doC(): void {
console.log('Component 2 does C.');
this.mediator.notify(this, 'C');
}
public doD(): void {
console.log('Component 2 does D.');
this.mediator.notify(this, 'D');
}
}
const c1 = new Component1();
const c2 = new Component2();
const mediator = new ConcreteMediator(c1, c2);
c1.doA();
c2.doD();
17. Memento Pattern
Captures and externalizes an object's internal state without violating encapsulation, so the object can be restored to this state later.
When to use: When you need to restore an object to a previous state.
Why to use: To provide the ability to restore an object to its previous state.
class Memento {
private state: string;
constructor(state: string) {
this.state = state;
}
public getState(): string {
return this.state;
}
}
class Originator {
private state: string;
public setState(state: string): void {
console.log(`Originator: Setting state to ${state}`);
this.state = state;
}
public save(): Memento {
return new Memento(this.state);
}
public restore(memento: Memento): void {
this.state = memento.getState();
console.log(`Originator: State after restoring from Memento: ${this.state}`);
}
}
class Caretaker {
private mementos: Memento[] = [];
private originator: Originator;
constructor(originator: Originator) {
this.originator = originator;
}
public backup(): void {
console.log('Caretaker: Saving Originator\'s state...');
this.mementos.push(this.originator.save());
}
public undo(): void {
if (!this.mementos.length) {
return;
}
const memento = this.mementos.pop();
console.log('Caretaker: Restoring state to:', memento.getState());
this.originator.restore(memento);
}
}
const originator = new Originator();
const caretaker = new Caretaker(originator);
originator.setState('State1');
caretaker.backup();
originator.setState('State2');
caretaker.backup();
originator.setState('State3');
caretaker.undo(); // Caretaker: Restoring state to: State2
caretaker.undo(); // Caretaker: Restoring state to: State1
18. Observer Pattern
Defines a one-to-many dependency between objects so that when one object changes state, all its dependents are notified and updated automatically.
When to use: When you need many other objects to receive an update when another object changes.
Why to use: To allow a single object to notify multiple other objects about changes in its state.
interface Observer {
update(subject: Subject): void;
}
class ConcreteObserverA implements Observer {
public update(subject: Subject): void {
if (subject.state < 3) {
console.log('ConcreteObserverA: Reacted to the event.');
}
}
}
class ConcreteObserverB implements Observer {
public update(subject: Subject): void {
if (subject.state === 0 || subject.state >= 2) {
console.log('ConcreteObserverB: Reacted to the event.');
}
}
}
class Subject {
public state: number;
private observers: Observer[] = [];
public attach(observer: Observer): void {
const isExist = this.observers.includes(observer);
if (isExist) {
return console.log('Subject: Observer has been attached already.');
}
this.observers.push(observer);
}
public detach(observer: Observer): void {
const observerIndex = this.observers.indexOf(observer);
if (observerIndex === -1) {
return console.log('Subject: Nonexistent observer.');
}
this.observers.splice(observerIndex, 1);
}
public notify(): void {
console.log('Subject: Notifying observers...');
for (const observer of this.observers) {
observer.update(this);
}
}
public someBusinessLogic(): void {
console.log('Subject: I\'m doing something important.');
this.state = Math.floor(Math.random() * 10);
console.log(`Subject: My state has just changed to: ${this.state}`);
this.notify();
}
}
const subject = new Subject();
const observer1 = new ConcreteObserverA();
subject.attach(observer1);
const observer2 = new ConcreteObserverB();
subject.attach(observer2);
subject.someBusinessLogic();
subject.someBusinessLogic();
19. State Pattern
Allows an object to alter its behavior when its internal state changes. The object will appear to change its class.
When to use: When an object must change its behavior at runtime depending on its state.
Why to use: To simplify state-specific behavior and transitions.
class Context {
private state: State;
constructor(state: State) {
this.transitionTo(state);
}
public transitionTo(state: State): void {
console.log(`Context: Transition to ${(<any>state).constructor.name}.`);
this.state = state;
this.state.setContext(this);
}
public request1(): void {
this.state.handle1();
}
public request2(): void {
this.state.handle2();
}
}
abstract class State {
protected context: Context;
public setContext(context: Context) {
this.context = context;
}
public abstract handle1(): void;
public abstract handle2(): void;
}
class ConcreteStateA extends State {
public handle1(): void {
console.log('ConcreteStateA handles request1.');
console.log('ConcreteStateA wants to change the state of the context.');
this.context.transitionTo(new ConcreteStateB());
}
public handle2(): void {
console.log('ConcreteStateA handles request2.');
}
}
class ConcreteStateB extends State {
public handle1(): void {
console.log('ConcreteStateB handles request1.');
}
public handle2(): void {
console.log('ConcreteStateB handles request2.');
console.log('ConcreteStateB wants to change the state of the context.');
this.context.transitionTo(new ConcreteStateA());
}
}
const context = new Context(new ConcreteStateA());
context.request1();
context.request2();
20. Strategy Pattern
Defines a family of algorithms, encapsulates each one, and makes them interchangeable.
When to use: When you have multiple algorithms for a specific task and you want to switch between them at runtime.
Why to use: To choose the appropriate algorithm at runtime.
interface Strategy {
doAlgorithm(data: string[]): string[];
}
class ConcreteStrategyA implements Strategy {
public doAlgorithm(data: string[]): string[] {
return data.sort();
}
}
class ConcreteStrategyB implements Strategy {
public doAlgorithm(data: string[]): string[] {
return data.reverse();
}
}
class Context {
private strategy: Strategy;
constructor(strategy: Strategy) {
this.strategy = strategy;
}
public setStrategy(strategy: Strategy) {
this.strategy = strategy;
}
public doSomeBusinessLogic(): void {
const result = this.strategy.doAlgorithm(['a', 'b', 'c', 'd', 'e']);
console.log(result.join(','));
}
}
const context = new Context(new ConcreteStrategyA());
context.doSomeBusinessLogic(); // a,b,c,d,e
context.setStrategy(new ConcreteStrategyB());
context.doSomeBusinessLogic(); // e,d,c,b,a
21. Template Method Pattern
Defines the skeleton of an algorithm in a method, deferring some steps to subclasses.
When to use: When you want to let subclasses redefine certain steps of an algorithm without changing its structure
.
Why to use: To prevent code duplication and ensure the algorithm's structure stays unchanged.
abstract class AbstractClass {
public templateMethod(): void {
this.baseOperation1();
this.requiredOperations1();
this.baseOperation2();
this.hook1();
this.requiredOperations2();
this.baseOperation3();
this.hook2();
}
protected baseOperation1(): void {
console.log('AbstractClass says: I am doing the bulk of the work');
}
protected baseOperation2(): void {
console.log('AbstractClass says: But I let subclasses override some operations');
}
protected baseOperation3(): void {
console.log('AbstractClass says: But I am doing the bulk of the work anyway');
}
protected abstract requiredOperations1(): void;
protected abstract requiredOperations2(): void;
protected hook1(): void { }
protected hook2(): void { }
}
class ConcreteClass1 extends AbstractClass {
protected requiredOperations1(): void {
console.log('ConcreteClass1 says: Implemented Operation1');
}
protected requiredOperations2(): void {
console.log('ConcreteClass1 says: Implemented Operation2');
}
}
class ConcreteClass2 extends AbstractClass {
protected requiredOperations1(): void {
console.log('ConcreteClass2 says: Implemented Operation1');
}
protected requiredOperations2(): void {
console.log('ConcreteClass2 says: Implemented Operation2');
}
protected hook1(): void {
console.log('ConcreteClass2 says: Overridden Hook1');
}
}
const concreteClass1 = new ConcreteClass1();
concreteClass1.templateMethod();
const concreteClass2 = new ConcreteClass2();
concreteClass2.templateMethod();
22. Visitor Pattern
Lets you separate algorithms from the objects on which they operate.
When to use: When you need to perform operations across a heterogeneous collection of objects.
Why to use: To avoid polluting object classes with unrelated behaviors.
interface Visitor {
visitConcreteComponentA(element: ConcreteComponentA): void;
visitConcreteComponentB(element: ConcreteComponentB): void;
}
class ConcreteVisitor1 implements Visitor {
public visitConcreteComponentA(element: ConcreteComponentA): void {
console.log(`${element.exclusiveMethodOfConcreteComponentA()} + ConcreteVisitor1`);
}
public visitConcreteComponentB(element: ConcreteComponentB): void {
console.log(`${element.specialMethodOfConcreteComponentB()} + ConcreteVisitor1`);
}
}
class ConcreteVisitor2 implements Visitor {
public visitConcreteComponentA(element: ConcreteComponentA): void {
console.log(`${element.exclusiveMethodOfConcreteComponentA()} + ConcreteVisitor2`);
}
public visitConcreteComponentB(element: ConcreteComponentB): void {
console.log(`${element.specialMethodOfConcreteComponentB()} + ConcreteVisitor2`);
}
}
interface Component {
accept(visitor: Visitor): void;
}
class ConcreteComponentA implements Component {
public accept(visitor: Visitor): void {
visitor.visitConcreteComponentA(this);
}
public exclusiveMethodOfConcreteComponentA(): string {
return 'A';
}
}
class ConcreteComponentB implements Component {
public accept(visitor: Visitor): void {
visitor.visitConcreteComponentB(this);
}
public specialMethodOfConcreteComponentB(): string {
return 'B';
}
}
const components = [new ConcreteComponentA(), new ConcreteComponentB()];
console.log('The client code works with all visitors via the base Visitor interface:');
const visitor1 = new ConcreteVisitor1();
for (const component of components) {
component.accept(visitor1);
}
console.log('It allows the same client code to work with different types of visitors:');
const visitor2 = new ConcreteVisitor2();
for (const component of components) {
component.accept(visitor2);
}
Subscribe to receive updates from me!
